19mm Carbon Steel Coil Sheet Metal HDG GI SECC Zinc Coated AZ
Product Details:
| Place of Origin: | China |
| Brand Name: | TISCO,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification: | MTC; SGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 Ton |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Coils covered with waterproof protective packing materails |
| Delivery Time: | 10-25 working days |
| Payment Terms: | T/T |
| Supply Ability: | 300 tons per month |
|
Detail Information |
|||
| Name: | Galvanized Steel Coil | Width: | 1250 Mm |
|---|---|---|---|
| Material: | SGCC CGCC TDC51DZM TDC52D TS350GD | Price Term: | FOB, CFR, CIF |
| Special Use: | Silicon Steel | Processing Service: | Bending, Welding, Decoiling, Cutting, Punching |
| 95-q345 Coil Weigh: | 3-10 Tons | Packing: | Standard Seaworthy Package |
| Zinc Coating: | 30-275g/m2 | ||
| High Light: | Zinc Coated Steel Coil,19mm Carbon Steel Coil,HDG Steel Coil |
||
Product Description
0.8x17mm 19mm 32mm Steel Sheet Metal PPGI HDG GI SECC DX51 Zinc Coated AZ
Galvanized steel is used to make corrosion-resistant nuts, bolts, and nails. It's used for outdoor pipes when plastic piping is not strong enough. It's used for bus stop benches, balconies, verandahs, staircases, walkways, and ladders
Product introduction :
| Commodity | 0.8x17mm 19mm 32mm Steel Sheet Metal PPGI HDG GI SECC DX51 Zinc Coated AZ |
| Grade | SECC |
| Brand | SHOUGANG; ANSTEEL; MASTEEL; BXSTEEL |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.8 MM |
| Width | 1250 MM |
| Length | 2500 MM |
| Surface | GI |
| Standard | JIS,AISI,ASTM,GB,DIN, BS EN, AS |
| Delivery time | About 25 or based on the sales contract |
| MOQ | 10 Ton |
|
|
Advantages:
- Lowest first cost. Galvanizing is lower in first cost than many other commonly specified protective coatings for steel. ...
- Less maintenance/Lowest long term cost. ...
- Long life. ...
- Reliability. ...
- Toughest coating. ...
- Automatic protection for damaged areas. ...
- Complete protection. ...
- Ease of inspection.
Application:
Gauge Size Table:
| Gauge | SS inch | SS mm | Mild Steel | Galvanized Steel |
| 3 | 0.25 | 6.35 | 0.2391 | |
| 4 | 0.2344 | 5.95376 | 0.2242 | |
| 5 | 0.2187 | 5.55498 | 0.2092 | |
| 6 | 0.2031 | 5.15874 | 0.1943 | |
| 7 | 0.1875 | 4.7625 | 0.1793 | |
| 8 | 0.165 | 4.191 | 0.1644 | 0.168 |
| 9 | 0.1562 | 3.96748 | 0.1495 | 0.1532 |
| 10 | 0.1406 | 3.57124 | 0.1345 | 0.1382 |
| 11 | 0.125 | 3.175 | 0.1196 | 0.1233 |
| 12 | 0.1094 | 2.77876 | 0.1046 | 0.1084 |
| 13 | 0.0937 | 2.37998 | 0.0897 | 0.0934 |
| 14 | 0.0781 | 1.98374 | 0.0747 | 0.0785 |
| 15 | 0.0703 | 1.78562 | 0.0673 | 0.071 |
| 16 | 0.0625 | 1.5875 | 0.0598 | 0.0635 |
| 17 | 0.0562 | 1.42748 | 0.0538 | 0.0575 |
| 18 | 0.05 | 1.27 | 0.0478 | 0.0516 |
| 19 | 0.0437 | 1.10998 | 0.0418 | 0.0456 |
| 20 | 0.0375 | 0.9525 | 0.0359 | 0.0396 |
| 21 | 0.0344 | 0.87376 | 0.0329 | 0.0366 |
| 22 | 0.0312 | 0.79248 | 0.0299 | 0.0336 |
Surface finish :
| Surface Finish | Definition | Application |
| 2B | Finished by heat treatment, pickling after cold rolling. Followed by skin pass line to be more brighter and smooth surface | General application Medical instruments, Tableware |
| BA | Bright heat treament after cold rolling | Kitchen utensil, kitchenware, architectural |
| 8K | A mirror-like reflective surface by polishing with finer abrasives over 800mesh | Construction, mirrors, plate sets, decoration elevators |
| HL | Finished by continuous linear polishing | Architectural purpose, Escalators, kitchenware, vehicles |
| NO.1 | Finished by hot rolling, annealing and picking, characterized by white pickled surface | Chemical industry Equipment, industrail tanks |
| NO.4 | Polishing with NO.150 to NO.180 mesh abrasives specified in JISR6001 | Kitchen utensils, Building Construction, Medical equipment |
Is galvanized steel an alloy?
Galvannealed steel is a zinc-iron alloy product, where the base metal is coated by the hot-dip process, then heated to induce alloying between the molten zinc coating and the steel
Packaging :
0.8x17mm 19mm 32mm Steel Sheet Metal PPGI HDG GI SECC DX51 Zinc Coated AZ packaging details :
1: Coils covered with waterproof protective packing materails ;
2: Then loaded in strong metal pallets +angle bar protection +steel strip ;
3: Well loaded and be transported to the loading port .
The innner size container as below :
1: 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM ;
2: 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM ;
3: 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM.
