3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects

3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects

Product Details:

Place of Origin: China
Brand Name: TISCO,BAOSTEEL,POSCO,JISCO,LISCO
Certification: MTC; SGS

Payment & Shipping Terms:

Minimum Order Quantity: 1Ton
Price: Negotiable
Packaging Details: waterproof paper and steel strip reinforcement,one package about 2 tons,Load in 20' or 40' GP
Delivery Time: 3-15 working days
Payment Terms: L/C, T/T
Supply Ability: 200 Tons per month
Get Best Price Contact Now

Detail Information

Name: 410 430 304 Hot Rolled Structural Steel Thickness: 3 Mm
Type: Plate Shape: Flat Sheet Coil
Surface: NO.1/NO.3/NO.4/8K/HL/2D/1D Color: Natual Color
Application: Construction, Industry, Decoration Steel Grade: 301L, 301, 410, 316Ti, 316L, 316, 321, 410S, 410L, 436L, 314, 430, 304, 439, 409L, 436, 304L, 405
Length: 1219 Mm Width: 2438 Mm
High Light:

3 Mm Thick Stainless Steel Sheet

,

Structural Projects Stainless Steel Sheet

,

410 hot rolled stainless steel plate

Product Description

410 430 304 Hot Rolled Structural Steel Thk 3 Mm Prime HR SS Plates



The absence of nickel in 430 grade means the stainless steel will most likely crack or fail completely compared to pressing 304. 304 grade stainless steel is also known as food grade stainless steel.


Product introduction:



Stainless steel plate/sheet
Product name Stainless steel plate/sheet
Standard GB,JIS,DIN,AISI,ASTM,AISI,ASME
Thickness 0.2mm-150mm
Width 1000,1219,1250,1500mm, or as your requirements
Length 2000,2438,2500,3000,6000mm, or as your requirements
MOQ 1MT
Surface No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Packing standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Cargo ready date within 25-35 days after confirming orders
Delivery Time About 5-7 days after receive the deposit.
Application Stainless Steel plates applies to construction field, ships building industry, petroleum and chemical industries , war and electricity industries, war and electricity industries, food processing and medical industries ,boiler heat exchanger, machinery and hardware field



Brand Cross Reference Table:



GB NEW BRAND JIS ASTM UNS KS BS EN AS
06Cr19Ni10 SUS304 304 S30400 STS304 1.4301 304
12Cr13 SUS410 410 S41000 STS410 1.4006 410
10Cr17 SUS430 430 S43000 STS430 1.4016 430


Gauge and Inch:



Gauge SS inch SS mm Mild Steel Galvanized Steel

3 0.25 6.35 0.2391
4 0.2344 5.95376 0.2242
5 0.2187 5.55498 0.2092
6 0.2031 5.15874 0.1943
7 0.1875 4.7625 0.1793
8 0.165 4.191 0.1644 0.168
9 0.1562 3.96748 0.1495 0.1532
10 0.1406 3.57124 0.1345 0.1382
11 0.125 3.175 0.1196 0.1233
12 0.1094 2.77876 0.1046 0.1084
13 0.0937 2.37998 0.0897 0.0934
14 0.0781 1.98374 0.0747 0.0785
15 0.0703 1.78562 0.0673 0.071
16 0.0625 1.5875 0.0598 0.0635
17 0.0562 1.42748 0.0538 0.0575
18 0.05 1.27 0.0478 0.0516
19 0.0437 1.10998 0.0418 0.0456
20 0.0375 0.9525 0.0359 0.0396
21 0.0344 0.87376 0.0329 0.0366
22 0.0312 0.79248 0.0299 0.0336
23 0.0281 0.71374 0.0269 0.0306
24 0.025 0.635 0.0239 0.0276
25 0.0219 0.55626 0.0209 0.0247


Chemical Composition:



Grade C Si Mn P S Ni Cr Mo
304 ≤0.07 ≤1.00 ≤2.00 ≤0.045 ≤0.03 8.0010.00 18.0020.00 -
410 ≤0.15 ≤1.00 ≤1.00 ≤0.040 ≤0.03   11.50013.50 -
430 ≤0.12 ≤1.00 ≤1.00 ≤0.040 ≤0.03   16.0018.00 -



Physical Property:



Grade Tensile Strength(Mpa) Yield Strength(Mpa) Elongation(%) HBW HRB HV
304 ≥520 ≥205 ≥40 ≤187 ≤90 ≤200
410 ≥440 ≥205 ≥20 ≤201 ≤93 ≤210
430 ≥450 ≥205 ≥22 ≤183 ≤88 ≤200


Uses:



Type 430 stainless steel cannot be hardened by heat treatment. Annealing is done by heating to 815°C, soaking for 30minutes per 25mm of thickness, furnace cooling to 600°C, then quickly air-cooling. The component will become brittle if slow cooled from 540-400°C.



Surface Finish:



3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects 0



Surface Finish Definition Application
2B Finished by heat treatment, pickling after cold rolling. Followed by skin pass line to be more brighter and smooth surface General application Medical instruments, Tableware
BA Bright heat treament after cold rolling Kitchen utensil, kitchenware, architectural
8K A mirror-like reflective surface by polishing with finer abrasives over 800mesh Construction, mirrors, plate sets, decoration elevators
HL Finished by continuous linear polishing Architectural purpose, Escalators, kitchenware, vehicles
NO.1 Finished by hot rolling, annealing and picking, characterized by white pickled surface Chemical industry Equipment, industrail tanks
NO.4 Polishing with NO.150 to NO.180 mesh abrasives specified in JISR6001 Kitchen utensils, Building Construction, Medical equipment



Packing:



410 430 304 Hot Rolled Structural Steel Thk 3 Mm Prime HR SS Plates 2 types:



l Standard packing



3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects 1



l Fine packing



3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects 2



Factory and Machine Equipment:



We had our own factory to do slitting re-rolling and finish treatment machine,PVC and interleaving paper we will using with our machine for you,could protect stainless steel surface from damage or any scratches,



1. CNC Flame Cutting Machine

2. CNC Plasma Cutting Machine

3. CNC Laser Cutting Machine

4. Bending Machine

5. Shearing Machine

6. Punch Machine

7. Driving Machine



410 430 304 Hot Rolled Structural Steel Thk 3 Mm Prime HR SS Plates Diaplay:



3 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects 33 Mm Thick Hot Rolled Stainless Steel Sheet 410 430 304 For Structural Projects 4



WHY CHOOSE US:



Q1: What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery. We will show you the photos of products and package before you pay the balance.

Q2: what is the terms of delivery?
A: FOB, CIF, CFR,

Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.

Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit.
For production period, it usually takes about 15 days-30 days after receiving the deposit.

Q5: Could you produce according to the samples?
A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.

Q6: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.
