304 Hot Rolled Stainless Steel Sheet with No.1 Finish for Atmospheric Corrosion Resistance
Product Details:
| Place of Origin: | China |
| Brand Name: | TISCO,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification: | MTC; SGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Ton |
|---|---|
| Price: | Negotiable |
| Packaging Details: | waterproof paper and steel strip reinforcement,one package about 2 tons,Load in 20' or 40' GP |
| Delivery Time: | 3-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 Tons per month |
|
Detail Information |
|||
| Name: | Stainless Steel Hot Rolled Plate Customer Cut | Thickness: | 3-120mm |
|---|---|---|---|
| Type: | Plate | Technique: | Hot Rolled |
| Surface: | NO.1/NO.3/NO.4/8K/HL/2D/1D | Color: | Natual Color |
| Application: | Construction, Industry, Decoration, Machine Building, Chemical | Processing Service: | Bending, Welding, Decoiling, Punching, Cutting |
| Standard: | JIS ASTM UNS KS BS EN AS | Edge: | Mill Edge Slit Edge |
| High Light: | 304 Hot Rolled Stainless Steel Sheet,Atmospheric Corrosion Resistance Stainless Steel Sheet,NO.1 hot rolled stainless steel 304 |
||
Product Description
4x8 Stainless Steel Sheet 304 Hot Rolled Plate No.1 Finish Customer Cut
Stainless acid-resistant steel is referred to as stainless steel. It is composed of stainless steel and acid-resistant steel. In short, steel that can resist atmospheric corrosion is called stainless steel, and steel that can resist chemical media corrosion is called acid-resistant steel. Rusty steel is a high-alloy steel with more than 60% iron as the matrix and adding alloying elements such as chromium, nickel, and molybdenum.
Product introduction:
|
Brand Cross Reference Table:
| GB NEW BRAND | JIS | ASTM | UNS | KS | BS EN | AS |
| 12Cr17Mn6Ni5N | SUS201 | 201 | S20100 | STS201 | 1.4372 | 201-2 |
| 12Cr18Mn9Ni5N | SUS202 | 202 | S20200 | STS202 | 1.4373 | - |
| 12Cr17Ni7 | SUS301 | 301 | S30100 | STS301 | 1.4319 | 301 |
| 06Cr19Ni10 | SUS304 | 304 | S30400 | STS304 | 1.4301 | 304 |
| 022Cr19Ni10 | SUS304L | 304L | S30403 | STS304L | 1.4306 | 304L |
| 06Cr19Ni10N | SUS304N1 | 304N | S30451 | STS304N1 | 1.4315 | 304N1 |
| 06Cr19Ni9NbN | SUS304N2 | XM21 | S30452 | STS304N2 | - | 304N2 |
| 022Cr19Ni10N | SUS304LN | 304LN | S30453 | STS304LN | - | 304LN |
| 10Cr18Ni12 | SUS305 | 305 | S30500 | STS305 | 1.4303 | 305 |
| 06Cr23Ni13 | SUS309S | 309S | S30908 | STS309S | 1.4833 | 309S |
| 06Cr25Ni20 | SUS310S | 310S | S31008 | STS310S | 1.4845 | 310S |
| 06Cr17Ni12Mo2 | SUS316 | 3016 | S31600 | STS316 | 1.4401 | 316 |
| 06Cr17Ni12Mo2Ti | SUS316Ti | 316Ti | S31635 | - | 1.4571 | 316Ti |
| 022Cr17Ni12Mo2 | SUS316L | 316L | S31603 | STS316L | 1.4404 | 316L |
| 06Cr17Ni12Mo2N | SUS316N | 316N | S31651 | STS316N | - | 316N |
| 022Cr17Ni13Mo2N | SUS316LN | 316LN | S31653 | STS316LN | 1.4429 | 316LN |
| 06Cr18Ni12Mo2Cu2 | SUS316J1 | - | - | STS316J1 | - | 316J1 |
| 022Cr18Ni14Mo2Cu2 | SUS316J1L | - | - | STS316J1L | - | - |
| 06Cr19Ni13Mo3 | SUS317 | 317 | S31700 | STS317 | - | 317 |
| 022Cr19Ni13Mo3 | SUS317L | 317L | S31703 | STS317L | 1.4438 | 317L |
| 06Cr18Ni11Tji | SUS321 | 321 | S32100 | STS321 | 1.4541 | 321 |
| 06Cr18Ni11Nb | SUS347 | 347 | S34700 | STS347 | 1.455 | 347 |
| 12Cr13 | SUS410 | 410 | S41000 | STS410 | 1.4006 | 410 |
| 20Cr13 | SUS420J1 | 420 | S42000 | STS420J1 | 1.4021 | 420 |
| 10Cr17 | SUS430 | 430 | S43000 | STS430 | 1.4016 | 430 |
Gauge and Inch:
| Gauge | Mild Steel | Aluminum | Galvanized Steel | Stainless Steel |
| 3 | 0.2391 | 0.2294 | 0.2500 | |
| 4 | 0.2242 | 0.2043 | 0.2344 | |
| 5 | 0.2092 | 0.1819 | 0.2187 | |
| 6 | 0.1943 | 0.1620 | 0.2031 | |
| 7 | 0.1793 | 0.1443 | 0.1875 | |
| 8 | 0.1644 | 0.1285 | 0.1680 | 0.1650 |
| 9 | 0.1495 | 0.1144 | 0.1532 | 0.1562 |
| 10 | 0.1345 | 0.1019 | 0.1382 | 0.1406 |
| 11 | 0.1196 | 0.0907 | 0.1233 | 0.1250 |
| 12 | 0.1046 | 0.0808 | 0.1084 | 0.1094 |
| 13 | 0.0897 | 0.0720 | 0.0934 | 0.0937 |
| 14 | 0.0747 | 0.0641 | 0.0785 | 0.0781 |
| 15 | 0.0673 | 0.0571 | 0.0710 | 0.0703 |
| 16 | 0.0598 | 0.0508 | 0.0635 | 0.0625 |
| 17 | 0.0538 | 0.0453 | 0.0575 | 0.0562 |
| 18 | 0.0478 | 0.0403 | 0.0516 | 0.0500 |
| 19 | 0.0418 | 0.0359 | 0.0456 | 0.0437 |
| 20 | 0.0359 | 0.0320 | 0.0396 | 0.0375 |
| 21 | 0.0329 | 0.0285 | 0.0366 | 0.0344 |
| 22 | 0.0299 | 0.0253 | 0.0336 | 0.0312 |
| 23 | 0.0269 | 0.0226 | 0.0306 | 0.0281 |
| 24 | 0.0239 | 0.0201 | 0.0276 | 0.0250 |
| 25 | 0.0209 | 0.0179 | 0.0247 | 0.0219 |
| 26 | 0.0179 | 0.0159 | 0.0217 | 0.0187 |
| 27 | 0.0164 | 0.0142 | 0.0202 | 0.0172 |
| 28 | 0.0149 | 0.0126 | 0.0187 | 0.0156 |
| 29 | 0.0135 | 0.0113 | 0.0172 | 0.0141 |
| 30 | 0.0120 | 0.0100 | 0.0157 | 0.0125 |
| 31 | 0.0105 | 0.0089 | 0.0142 | 0.0109 |
| 32 | 0.0097 | 0.0080 | 0.0134 | 0.0102 |
| 33 | 0.0090 | 0.0071 | 0.0094 | |
| 34 | 0.0082 | 0.0063 | 0.0086 | |
| 35 | 0.0075 | 0.0056 | 0.0078 | |
| 36 | 0.0067 | 0.0070 |
Chemical Composition:
| Grade | Chemical Composition (WT %) | ||||||
| Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | |
| 304 | ≤ 0.07 | ≤ 2.00 | ≤ 0.045 | ≤ 0.030 | ≤ 1.00 | 18.0 to 20.0 | ≤ 8.0 to 10.0 |
Physical Property:
| Physical Property | |||||
| Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | / | Hardness(HV/HB) | Density |
| ≥520MPa | ≥205MPa | ≥40% | / | ≤200HV | 7.93g/cm3 |
When the chromium content in the steel exceeds 12%, the steel is not easy to corrode and rust in the air and dilute nitric acid. The reason is that chromium can form a very tight chromium oxide film on the surface of the steel, which effectively protects the steel from corrosion. The chromium content in stainless steel generally exceeds 14%, but stainless steel is not absolutely rust-free. In coastal areas or some places with serious air pollution, when the chlorine ion content in the air is high, the stainless steel surface exposed to the atmosphere may have some rust spots, but these rust spots are limited to the surface and will not erode the internal matrix of the stainless steel.
Surface Finish:
| Surface Finish | Definition | Application |
| 2B | Finished by heat treatment, pickling after cold rolling. Followed by skin pass line to be more brighter and smooth surface | General application Medical instruments, Tableware |
| BA | Bright heat treament after cold rolling | Kitchen utensil, kitchenware, architectural |
| 8K | A mirror-like reflective surface by polishing with finer abrasives over 800mesh | Construction, mirrors, plate sets, decoration elevators |
| HL | Finished by continuous linear polishing | Architectural purpose, Escalators, kitchenware, vehicles |
| NO.1 | Finished by hot rolling, annealing and picking, characterized by white pickled surface | Chemical industry Equipment, industrail tanks |
| NO.4 | Polishing with NO.150 to NO.180 mesh abrasives specified in JISR6001 | Kitchen utensils, Building Construction, Medical equipment |
Packing:
4x8 stainless steel sheet 304 hot rolled plate No.1 finish customer cut 2 types:
l Standard packing
l Fine packing
Factory and Machine Equipment:
We had our own factory to do slitting re-rolling and finish treatment machine,PVC and interleaving paper we will using with our machine for you,could protect stainless steel surface from damage or any scratches,
1. CNC Flame Cutting Machine
2. CNC Plasma Cutting Machine
3. CNC Laser Cutting Machine
4. Bending Machine
5. Shearing Machine
6. Punch Machine
7. Driving Machine
