Corrosion Resistant 316Ti Seamless Stainless Steel Pipe For Chemical And Industrial
Product Details:
| Place of Origin: | China |
| Brand Name: | no brand |
| Certification: | MTC; SGS |
| Model Number: | 316Ti |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Ton |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Pipes will be covered with waterproof protective packing materials; |
| Delivery Time: | 15-30 working days |
| Supply Ability: | 100 Tons per month |
|
Detail Information |
|||
| Name: | 316L Seamless Ss Pipe | Shape: | Round |
|---|---|---|---|
| Outer Diameter: | 168.3 Mm | Thickness: | 3.4mm |
| Length: | 12M, 6m, 6.4M | Finish: | Annealed Or Un Annealed |
| Secondary Or Not: | Non-secondary | Grade: | ASTM A312 TP316L |
| Standard: | ASTM 312 | MOQ: | 1 Ton |
| High Light: | Corrosion Resistant Seamless Stainless Steel Pipe,Industrial Seamless Stainless Steel Pipe,Chemical Seamless Stainless Steel Pipe |
||
Product Description
Corrosion Resistant 316Ti Seamless Stainless Steel Pipe for Chemical and Industrial
316Ti stainless steel stands as a paragon of durability with its enhanced resistance to corrosion, particularly against chlorides and other industrial solvents. This remarkable capability is achieved through its enriched composition, including a minimum of 10.5% chromium, molybdenum, and the addition of titanium. The titanium stabilizes the structure against chromium carbide formation, making 316Ti the ideal choice for marine environments, chemical processing, and other aggressive contexts where standard grades may falter. This alloy ensures that structures and equipment maintain integrity and appearance over extended periods, even in the face of relentless environmental challenge.
Product introduction:
| Commodity | Corrosion Resistant 316Ti Seamless Stainless Steel Pipe for Chemical and Industrial |
| Grade | 316Ti |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Wall Thickness | 3.4mm |
| Outside diameter | 168.3mm |
| Length | 1000-6000mm |
| Surface | Pickled |
| Technique | seamless |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery time | About 15 -30 days or based on the sales contract |
| MOQ | 1 Ton |
| Advantages |
316Ti stainless steel is added Ti to SUS316 steel to improve intergranular corrosion resistance. The equipment is used to resist sulfuric acid, phosphoric acid, acetic acid and acetic acid . |
Chemical Composition:
| Grade | Chemical Composition (WT %) | |||||||
| C | Mn | P | S | Si | Cr | Ni | Ti | |
| 316Ti | ≤ 0.08 | ≤ 2.00 | ≤ 0.035 | ≤ 0.030 | ≤ 1.00 | 16.00 to 18.00 | 11.00-14.00 | 0.20-0.70 |
Physical Property:
| Physical Property | |||||
| Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | / | Hardness(HV/HB) | Density |
| ≥520MPa | ≥205MPa | ≥40% | / | ≤200HV | 7.98g/cm3 |
The following table is the size of the stainless steel seamless tube. For any other detail information, please feel free to contact us.
Typicall material :
| Seamless and redrawn | |||
| ASTM Grade | UNS no. | Condition | Specifications |
| 304 | S30400 | Hard | AMS 5566/5564 |
| 304 | S30400 | Hard | MILT 5695 |
| 304 | S30400 | Hard | LN 9396 |
| 304 | S30400 | Hard | LN 9398 |
| 304 | S30400 | Annealed | MILT 8504 |
| 304L | S30403 | Hard | AMS 5569 |
| 304L | S30403 | Hard or annealed | AIR 9164 |
| 304L | S30403 | Hard or annealed | AIR 9160 |
| 304L | S30403 | Annealed | AIR 9423 |
| 304L | S30403 | Annealed | AIR 9424 |
| 321 | S32100 | Annealed | AMS 5645, AMS 5557/5570 |
| 321 | S32100 | Hard or annealed | AIR 9164 |
| 321 | S32100 | Hard or annealed | AIR 9160 |
| 321 | S32100 | Annealed | AIR 9423 |
| 321 | S32100 | Annealed | AIR 9424 |
| 321 | S32100 | Annealed | BSI T67 |
| 321 | S32100 | Annealed | LN 9396 |
| 321 | S32100 | Annealed | MILT 8808 |
| 321/347 | S34700 | Annealed | LN 9398 |
| 347 | S34700 | Annealed | AMS 5571/5556 |
| 347 | S34700 | Hard | BSI T68 |
| 347 | S34700 | Annealed | BSI T66 |
| 347 | S34700 | Annealed | BSI T72 |
| 347 | S34700 | Annealed | MILT 8808 |
| 304/304L | S30400/S30403 | Hard | MILT 6845 |
| 304L/321/347 | S30403/S32100/S34700 | Annealed | MILT 8606 |
| 304L/316L/321/347 | S30403/S32100/S34700 | Hard | MILT 8973 |
| Alloy 625 | N06625 | Annealed | AMS 5581 |
| Alloy 718 | N07718 | Annealed | AMS 5590 |
| Nickel 200 | N02200 | Annealed |
|
SCH Table:
Surface Finish:
Packaging:
316Ti Seamless Stainless Steel Round Pipe 4 " Sch40 ASTM ASME Packaging Details:
1: Pipes be covered with waterproof protective packing materials;
2: Then be bundled with strips together;
3: Well loaded and be transported to the loading port.
The inner size container as below:
1:20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM ;
2:40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM ;
3:40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM.
316Ti stainless steel is added Ti to SUS316 steel to improve intergranular corrosion resistance.
Product display:
WHY CHOOSE US:
Q1: What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery. We will show you the photos of products and package before you pay the balance.
Q2: what is the terms of delivery?
A: FOB, CIF, CFR,
Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit.
For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5: Could you produce according to the samples?
A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
Q6: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.
