2B BA Finish 430 Cold Roll Steel Coil Coil Ferrite Stainless Steel Roll
Product Details:
Place of Origin: | China |
Brand Name: | TISCO,BAOSTEEL,POSCO,JISCO,LISCO |
Certification: | MTC; SGS |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Ton |
---|---|
Price: | Negotiable |
Packaging Details: | Coils covered with waterproof protective packing materails |
Delivery Time: | 3-15 working days |
Payment Terms: | L/C, T/T |
Supply Ability: | 200 tons per month |
Detail Information |
|||
Name: | 430 Stainless Steel Coil | Stock: | Stock |
---|---|---|---|
Technique: | Cold Rolled | Price Term: | FOB, CFR, CIF |
Standard: | 430 | Thickness: | 0-3 Mm |
Surface: | No.1 2b Ba Mirror | Packing: | Standard Seaworthy Package |
Service: | Sample And MTC | ||
High Light: | 2B cold rolled stainless steel coil,430 cold rolled stainless steel coil,BA cold rolled stainless steel coil |
Product Description
2B BA Finish 430 cold roll steel coil Coil Ferrite Stainless Steel Roll
The production process of cold rolled coils includes processes such as pickling, cold rolling, annealing, leveling, and shearing. Among them, pickling is to remove the oxide scale on the surface of hot-rolled plates, cold rolling is to reduce the thickness of the plate and improve the dimensional accuracy of the plate, annealing is to eliminate stress during the cold rolling process and improve the plasticity of the plate, leveling is to improve the surface quality and dimensional accuracy of the plate, and shearing is to cut the plate into the required length and width.
Product introduction :
Commodity | 2B BA Finish 430 cold roll steel coil Coil Ferrite Stainless Steel Roll |
Grade | 430 |
Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
Certification | SGS,BV,IQI,TUV,ISO,etc |
Thickness | 0-3 mm |
Width |
800 mm |
Length | as per customers'requirements |
Surface | BA & 2B Finish |
Standard | JIS,AISI,ASTM,GB,DIN, BS EN, AS |
Delivery time | About 15 days or based on the sales contract |
MOQ | 1 Ton |
Advantages |
Showing the splendor of your quality, wearresistant as well , |
Chemical composition:
Grade | C | Si | Mn | P | S | Ni | Cr | Mo | N |
430 | ≤0.12 | ≤1.00 | ≤1.00 | ≤0.040 |
≤0.0 3 |
16.00~18.00 | - |
Mechanical property:
Grade | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | HBW | HRB | HV |
430 | ≥450 | ≥205 | ≥22 | ≤183 | ≤88 | ≤200 |
Gauge Size Table:
Gauge | SS inch | SS mm | Mild Steel | Galvanized Steel |
3 | 0.25 | 6.35 | 0.2391 | |
4 | 0.2344 | 5.95376 | 0.2242 | |
5 | 0.2187 | 5.55498 | 0.2092 | |
6 | 0.2031 | 5.15874 | 0.1943 | |
7 | 0.1875 | 4.7625 | 0.1793 | |
8 | 0.165 | 4.191 | 0.1644 | 0.168 |
9 | 0.1562 | 3.96748 | 0.1495 | 0.1532 |
10 | 0.1406 | 3.57124 | 0.1345 | 0.1382 |
11 | 0.125 | 3.175 | 0.1196 | 0.1233 |
12 | 0.1094 | 2.77876 | 0.1046 | 0.1084 |
13 | 0.0937 | 2.37998 | 0.0897 | 0.0934 |
14 | 0.0781 | 1.98374 | 0.0747 | 0.0785 |
15 | 0.0703 | 1.78562 | 0.0673 | 0.071 |
16 | 0.0625 | 1.5875 | 0.0598 | 0.0635 |
17 | 0.0562 | 1.42748 | 0.0538 | 0.0575 |
18 | 0.05 | 1.27 | 0.0478 | 0.0516 |
19 | 0.0437 | 1.10998 | 0.0418 | 0.0456 |
20 | 0.0375 | 0.9525 | 0.0359 | 0.0396 |
21 | 0.0344 | 0.87376 | 0.0329 | 0.0366 |
22 | 0.0312 | 0.79248 | 0.0299 | 0.0336 |
Brand Cross Reference Table:
GB NEW BRAND | JIS | ASTM | UNS | KS | BS EN | AS |
10Cr17 | SUS430 | 430 | S43000 | STS430 | 1.4016 | 430 |
Surface finish :
Surface Finish | Definition | Application |
2B | Finished by heat treatment, pickling after cold rolling. Followed by skin pass line to be more brighter and smooth surface | General application Medical instruments, Tableware |
BA | Bright heat treament after cold rolling | Kitchen utensil, kitchenware, architectural |
8K | A mirror-like reflective surface by polishing with finer abrasives over 800mesh | Construction, mirrors, plate sets, decoration elevators |
HL | Finished by continuous linear polishing | Architectural purpose, Escalators, kitchenware, vehicles |
NO.1 | Finished by hot rolling, annealing and picking, characterized by white pickled surface | Chemical industry Equipment, industrail tanks |
NO.4 | Polishing with NO.150 to NO.180 mesh abrasives specified in JISR6001 | Kitchen utensils, Building Construction, Medical equipment |
Advantages of cold rolled stainless steel coil:
1. Cold rolled stainless steel coil has bright appearance, smooth surface in use, and strong plasticity. It can be used to make a variety of stainless steel paper products; Cold rolled stainless steel coil has good mechanical strength, which can ensure the strength of stainless steel products and prevent them from being damaged by collision; Cold rolled stainless steel coil has strong corrosion resistance and can resist the corrosion of acid, alkaline gas or other media; Because the stainless steel plate itself has a layer of oxide film, it can isolate the metal from the outside air, so that the stainless steel plate is protected from the hardness of the environment. Therefore, stainless steel can have good corrosion resistance;
2. The corrosion resistance of stainless steel mainly depends on its alloy composition and internal structure. Chromium plays a major role in use. It can form a passive film on the steel surface to protect the steel;
Packaging :
Product Display:
430 Stainless Steel Coil Ferrite Stainless Steel Roll 2B BA Finish packaging details :
1: Coils covered with waterproof protective packing materails ;
2: Then loaded in strong metal pallets +angle bar protection +steel strip ;
3: Well loaded and be transported to the loading port .
The innner size container as below :
1: 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM ;
2: 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM ;
3: 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM.
WHY CHOOSE US:
Q1: What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery. We will show you the photos of products and package before you pay the balance.
Q2: what is the terms of delivery?
A: FOB, CIF, CFR,
Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit.
For production period, it usually takes about 15 days-30 days after receiving the deposit.
Q5: Could you produce according to the samples?
A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.
Q6: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.
